對於物聯網(IoT)應用,需要兼顧高速和低速時鐘下運行的MCU。諸如被藍牙智慧,藍牙低功耗(BLE),WiFi,ZigBee和sub-GHz RF的無線通訊廣泛使用的16.0 / 24.0 / 32.0 / 40.0MHz和32.768KHz的典型頻率。HKC提供針對物聯網應用適配的全系列可靠頻率產品。

對於可穿戴設備,低功耗是一個主要要求。配備低ESR晶振的振盪電路是首選,HKC為可穿戴應用提供了一個選擇低ESR晶振的可能。

HKC的IoT晶振可用於不同的工作溫度範圍,從-20至+ 70°C(對於消費產品),-40至+ 85°C(工業應用)和-40至+ 125°C(嚴苛環境)。

外形小也並不總是趨勢!有許多物聯網產品,其中小外形不是一個問題,但成本是最關鍵的。 HKC仍然生產傳統的封裝尺寸,用於成本敏感的IoT應用。

新目錄 –高精度晶體的物聯網 (IoT)應用簡介  請按此處下載新目錄

型號 封裝尺寸 頻率 常溫頻差 溫度頻差 工作溫度 描述
CQ 2.0 x 1.6 mm 16MHz ~ 72MHz ±10 ppm ±10 / 20 ppm -20 ~ +70°C Extremely small form factor for wearable devices
CK 2.5 x 2.0 mm 16MHz ~ 80MHz ±10 ppm ±10 / 20 ppm -20 ~ +70°C Small footprint for most advance IoT applications
C7 3.2 x 2.5 mm 8MHz ~ 150MHz ±10 ppm ±10 / 20 ppm -20 ~ +70°C Best balance of cost performance in common package size
P8 3.2 x 1.5 mm 32.768KHz ±20 ppm -0.04ppm/°C2 -20 ~ +70°C Low frequency standby clock in small footprint
2T 6 x Φ2 mm 32.768KHz ±20 ppm -0.04ppm/°C2 -20 ~ +70°C Most cost effective in famous industry standard package


IC 品牌 IC 產品號 封裝 頻率 等效負載(pF) 訂購號 查詢 網上購物
Broadcom BCM43235 5032 Ceramic SMD-4 20 MHz 12 5032M2000AB9F question
Broadcom BCM43235 2520 Ceramic SMD-4 20 MHz 9 2520M2000AB9D question
Broadcom BCM4360 2520 Ceramic SMD-4 40 MHz 12 2520M4000AB9F question
CSR CSR1010 3225 Ceramic SMD-4 16 MHz 9 3225M1600AH9D question
CSR CSR1010 2520 Ceramic SMD-4 16 MHz 9 2520M1600AH9D question
CSR CSR8510 3225 Ceramic SMD-4 26 MHz 6 3225M2600AH9A question
CSR CSR8510 3225 Ceramic SMD-4 26 MHz 9 3225M2600AH9D question
DME DME_1080 HC49US SMD-2 16 MHz 8 SS00M1600AS9C question
Nordic nRF24AP2 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF24AP2 2520 Ceramic SMD-4 16 MHz 6 2520M1600BC9A question
Nordic nRF24L01 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF24LE1 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF24LU1 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF51/24/80 Series 3215 Ceramic SMD-2 32.768 KHz 9 3215K3276BC9D question
Nordic nRF51422 2520 Ceramic SMD-4 32 MHz 8 2520M3200BC9C question
Nordic nRF51422 2520 Ceramic SMD-4 16 MHz 8 2520M1600BC9C question
Nordic nRF51822 HC49US SMD-2 16 MHz 12 SS00M1600BC9F question
Nordic nRF51822 2520 Ceramic SMD-4 32 MHz 8 2520M3200BC9C question
Nordic nRF51822 2520 Ceramic SMD-4 16 MHz 8 2520M1600BC9C question
Nordic nRF51824 2520 Ceramic SMD-4 32 MHz 8 2520M3200BC9C question
Nordic nRF51824 2520 Ceramic SMD-4 16 MHz 8 2520M1600BC9C question
Nordic nRF8001 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF8001 2520 Ceramic SMD-4 16 MHz 6 2520M1600BC9A question
Nordic nRF8001 2016 Ceramic SMD-4 16 MHz 6 2016M1600BC9A question
Nordic nRF8002 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF8002 2520 Ceramic SMD-4 16 MHz 6 2520M1600BC9A question
Nordic nRF8002 2016 Ceramic SMD-4 16 MHz 6 2016M1600BC9A question
Nordic nRF905 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Nordic nRF9E5 3225 Ceramic SMD-4 16 MHz 9 3225M1600BC9D question
Remoteble RT400 3225 Ceramic SMD-4 12 MHz 8 3225M1200BF9C question
Remoteble RT400 HC49US SMD-2 12 MHz 20 SS00M1200BF9K question
St Microelectronics STM32 Series 2520 Ceramic SMD-4 24 MHz 20 2520M2400AK9K question
St Microelectronics STM32 Series 3215 Ceramic SMD-2 32.768 KHz 9 3215K3276AK9D question
TI CC2541 3225 Ceramic SMD-4 32 MHz 12 3225M3200AN9F question
TI CC2564 3225 Ceramic SMD-4 26 MHz 15 3225M2600AN9L question
TI CC2564 3225 Ceramic SMD-4 38.4 MHz 15 3225M3840AN9L question
TI CC2564 2016 Ceramic SMD-4 26 MHz 15 2016M2600AN9L question
TI CC2564 2016 Ceramic SMD-4 38.4 MHz 15 2016M3840AN9L question
TI CC2564 3215 Ceramic SMD-2 32.768 KHz 9 3215K3276AN9D question
TI CC2640 3225 Ceramic SMD-4 24 MHz 8 3225M2400AN9C question
TI CC2640 2016 Ceramic SMD-4 24 MHz 8 2016M2400AN9C question
TI CC2640 3215 Ceramic SMD-2 32.768 KHz 9 3215K3276AK9D question
TI CC2650 3225 Ceramic SMD-4 24 MHz 8 3225M2400AN9C question
TI CC2650 2016 Ceramic SMD-4 24 MHz 8 2016M2400AN9C question
TI CC2650 3215 Ceramic SMD-2 32.768 KHz 9 33215K3276AN5D question
TI CC3200 3225 Ceramic SMD-4 40 MHz 6.5 3225M4000AN9S question
TI CC3200 3225 Ceramic SMD-4 40 MHz 8 3225M4000AN9C question
TI CC3200 2016 Ceramic SMD-4 40 MHz 8 2016M4000AN9C question
TI CC3200 3215 Ceramic SMD-2 32.768 KHz 12.5 3215K3276AN9N question
TI CC3200 2×6 Cylinder 32.768 KHz 12.5 2060K3276AN9N question
