對於物聯網（IoT）應用，需要兼顧高速和低速時鐘下運行的MCU。諸如被藍牙智慧，藍牙低功耗（BLE），WiFi，ZigBee和sub-GHz RF的無線通訊廣泛使用的16.0 / 24.0 / 32.0 / 40.0MHz和32.768KHz的典型頻率。HKC提供針對物聯網應用適配的全系列可靠頻率產品。
對於可穿戴設備，低功耗是一個主要要求。配備低ESR晶振的振盪電路是首選，HKC為可穿戴應用提供了一個選擇低ESR晶振的可能。
HKC的IoT晶振可用於不同的工作溫度範圍，從-20至+ 70°C（對於消費產品），-40至+ 85°C（工業應用）和-40至+ 125°C（嚴苛環境）。
外形小也並不總是趨勢！有許多物聯網產品，其中小外形不是一個問題，但成本是最關鍵的。 HKC仍然生產傳統的封裝尺寸，用於成本敏感的IoT應用。
新目錄 –高精度晶體的物聯網 (IoT)應用簡介 請按此處下載
| 型號 | 封裝尺寸 | 頻率 | 常溫頻差 | 溫度頻差 | 工作溫度 | 描述 |
| CU | 1.2 x 1.0 mm | 32MHz ~ 80MHz | ±10 ppm | ±10 / 20 ppm | -30 ~ +85°C | Smallest size available |
| CT | 1.6 x 1.25 mm | 24MHz ~ 60MHz | ±10 ppm | ±10 / 20 ppm | -30 ~ +85°C | Suitable for ultra compact wearable devices |
| CQ | 2.0 x 1.6 mm | 16MHz ~ 72MHz | ±10 ppm | ±10 / 20 ppm | -30 ~ +85°C | Extremely small form factor for wearable devices |
| CK | 2.5 x 2.0 mm | 16MHz ~ 80MHz | ±10 ppm | ±10 / 20 ppm | -30 ~ +85°C | Small footprint for most advance IoT applications |
| C7 | 3.2 x 2.5 mm | 8MHz ~ 150MHz | ±10 ppm | ±10 / 20 ppm | -30 ~ +85°C | Best balance of cost performance in common package size |
| MU MT MQ MB |
1.2 x 1.0 mm 1.6 mm x 1.0 mm 2.0 mm x 1.2 mm 3.2 mm x 1.5 mm |
32.768kHz | ±20 ppm | 0.04ppm/°C2 | -30 ~ +85°C | Low frequency standby clock in small footprint |
| 2T | 6 x Φ2 mm | 32.768kHz | ±20 ppm | 0.04ppm/°C2 | -30 ~ +85°C | Most cost effective in famous industry standard package |
| IC 品牌 | IC 產品號 | 封裝 | 頻率 | 等效負載(pF) | 訂購號 | 查詢 | 網上購物 |
| Broadcom | BCM43235 | 5032 Ceramic SMD-4 | 20 MHz | 12 | 5032M2000AB9F |  |
 |
| Broadcom | BCM43235 | 2520 Ceramic SMD-4 | 20 MHz | 9 | 2520M2000AB9D | |
|
| Broadcom | BCM4360 | 2520 Ceramic SMD-4 | 40 MHz | 12 | 2520M4000AB9F | |
|
| CSR | CSR1010 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600AH9D | |
|
| CSR | CSR1010 | 2520 Ceramic SMD-4 | 16 MHz | 9 | 2520M1600AH9D | |
|
| CSR | CSR8510 | 3225 Ceramic SMD-4 | 26 MHz | 6 | 3225M2600AH9A | |
|
| CSR | CSR8510 | 3225 Ceramic SMD-4 | 26 MHz | 9 | 3225M2600AH9D | |
|
| DME | DME_1080 | HC49US SMD-2 | 16 MHz | 8 | SS00M1600AS9C | |
|
| Nordic | nRF24AP2 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF24AP2 | 2520 Ceramic SMD-4 | 16 MHz | 6 | 2520M1600BC9A | |
|
| Nordic | nRF24L01 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF24LE1 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF24LU1 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF51/24/80 Series | 3215 Ceramic SMD-2 | 32.768 KHz | 9 | 3215K3276BC9D | |
|
| Nordic | nRF51422 | 2520 Ceramic SMD-4 | 32 MHz | 8 | 2520M3200BC9C | |
|
| Nordic | nRF51422 | 2520 Ceramic SMD-4 | 16 MHz | 8 | 2520M1600BC9C | |
|
| Nordic | nRF51822 | HC49US SMD-2 | 16 MHz | 12 | SS00M1600BC9F | |
|
| Nordic | nRF51822 | 2520 Ceramic SMD-4 | 32 MHz | 8 | 2520M3200BC9C | |
|
| Nordic | nRF51822 | 2520 Ceramic SMD-4 | 16 MHz | 8 | 2520M1600BC9C | |
|
| Nordic | nRF51824 | 2520 Ceramic SMD-4 | 32 MHz | 8 | 2520M3200BC9C | |
|
| Nordic | nRF51824 | 2520 Ceramic SMD-4 | 16 MHz | 8 | 2520M1600BC9C | |
|
| Nordic | nRF8001 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF8001 | 2520 Ceramic SMD-4 | 16 MHz | 6 | 2520M1600BC9A | |
|
| Nordic | nRF8001 | 2016 Ceramic SMD-4 | 16 MHz | 6 | 2016M1600BC9A | |
|
| Nordic | nRF8002 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF8002 | 2520 Ceramic SMD-4 | 16 MHz | 6 | 2520M1600BC9A | |
|
| Nordic | nRF8002 | 2016 Ceramic SMD-4 | 16 MHz | 6 | 2016M1600BC9A | |
|
| Nordic | nRF905 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Nordic | nRF9E5 | 3225 Ceramic SMD-4 | 16 MHz | 9 | 3225M1600BC9D | |
|
| Remoteble | RT400 | 3225 Ceramic SMD-4 | 12 MHz | 8 | 3225M1200BF9C | |
|
| Remoteble | RT400 | HC49US SMD-2 | 12 MHz | 20 | SS00M1200BF9K | |
|
| St Microelectronics | STM32 Series | 2520 Ceramic SMD-4 | 24 MHz | 20 | 2520M2400AK9K | |
|
| St Microelectronics | STM32 Series | 3215 Ceramic SMD-2 | 32.768 KHz | 9 | 3215K3276AK9D | |
|
| TI | CC2541 | 3225 Ceramic SMD-4 | 32 MHz | 12 | 3225M3200AN9F | |
|
| TI | CC2564 | 3225 Ceramic SMD-4 | 26 MHz | 15 | 3225M2600AN9L | |
|
| TI | CC2564 | 3225 Ceramic SMD-4 | 38.4 MHz | 15 | 3225M3840AN9L | |
|
| TI | CC2564 | 2016 Ceramic SMD-4 | 26 MHz | 15 | 2016M2600AN9L | |
|
| TI | CC2564 | 2016 Ceramic SMD-4 | 38.4 MHz | 15 | 2016M3840AN9L | |
|
| TI | CC2564 | 3215 Ceramic SMD-2 | 32.768 KHz | 9 | 3215K3276AN9D | |
|
| TI | CC2640 | 3225 Ceramic SMD-4 | 24 MHz | 8 | 3225M2400AN9C | |
|
| TI | CC2640 | 2016 Ceramic SMD-4 | 24 MHz | 8 | 2016M2400AN9C | |
|
| TI | CC2640 | 3215 Ceramic SMD-2 | 32.768 KHz | 9 | 3215K3276AK9D | |
|
| TI | CC2650 | 3225 Ceramic SMD-4 | 24 MHz | 8 | 3225M2400AN9C | |
|
| TI | CC2650 | 2016 Ceramic SMD-4 | 24 MHz | 8 | 2016M2400AN9C | |
|
| TI | CC2650 | 3215 Ceramic SMD-2 | 32.768 KHz | 9 | 33215K3276AN5D | |
|
| TI | CC3200 | 3225 Ceramic SMD-4 | 40 MHz | 6.5 | 3225M4000AN9S | |
|
| TI | CC3200 | 3225 Ceramic SMD-4 | 40 MHz | 8 | 3225M4000AN9C | |
|
| TI | CC3200 | 2016 Ceramic SMD-4 | 40 MHz | 8 | 2016M4000AN9C | |
|
| TI | CC3200 | 3215 Ceramic SMD-2 | 32.768 KHz | 12.5 | 3215K3276AN9N | |
|
| TI | CC3200 | 2×6 Cylinder | 32.768 KHz | 12.5 | 2060K3276AN9N | |
|
