Oscillator (XO)

Oscillator (XO)


CMOS Output


Product Series Model Package Dimension
L x W x
H [mm]
Output Frequency Overall Frequency
Stability (ppm)
Supply
Voltage (V)
Operating Temperature Brief Sheet
[Automotive]
Brief Sheet
[Industrial]
Enquiry
 1612XO CY 4-Pad 1.65 x 1.25 x 0.8 CMOS 32.768KHz ;
1 MHz – 60MHz
±50ppm ~ ±100ppm 1.8V / 3.3V / 5V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 2016XO CX 4-Pad 2.0 x 1.6 x 0.8 CMOS 32.768KHz ;
1MHz – 80MHz
±30ppm ~ ±100ppm 1.8V / 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 2520XO CM 4-Pad 2.5 x 2.0 x 1.0 CMOS 32.768KHz ;
1MHz – 156.25MHz
±30ppm ~ ±100ppm 32.768KHz:
1.8 ~ 3.3V

1MHz – 156.25MHz:
1.8V ~ 5.0V
-20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 3225XO C8 4-Pad 3.2 x 2.5 x 1.2 CMOS 32.768KHz ;
1MHz – 156.25MHz
±25ppm ~ ±100ppm 32.768KHz:
1.8 ~ 3.3V

1MHz – 156.25MHz:
1.8V ~ 5.0V
-20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 5032XO C2 4-Pad 5.0 x 3.2 x 1.2 CMOS 32.768KHz;
0.625MHz – 160MHz
±25ppm ~ ±100ppm 1.8V ~ 5.0V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 7050XO C4 4-Pad 7.0 x 5.0 x 1.8 CMOS 32.768KHz;
0.5MHz – 160MHz
±25ppm ~ ±100ppm 1.8V ~ 5.0V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 14DIP CF Full Size 4-Pin 20.8 x 13.2 x 5.1 CMOS 1MHz – 100MHz ±25ppm ~ ±100ppm 1.8V ~ 5.0V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
 8DIP CH Half Size 4-Pin 12.8 x 12.8 x 5.5 CMOS 1MHz – 100MHz ±25ppm ~ ±100ppm 1.8V ~ 5.0V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)


LVPECL Output


Product Series Model Package Dimension
L x W x
H [mm]
Output Frequency Overall Frequency
Stability (ppm)
Supply
Voltage (V)
Operating Temperature Brief Sheet
[Automotive]
Brief Sheet
[Industrial]
Enquiry
 2520XO CM 6-Pad 2.5 x 2.0 x 1.0 LVPECL 100MHz – 156.25MHz ±20ppm ~ ±100ppm 2.5V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 3225XO C8 6-Pad 3.2 x 2.5 x 0.95 LVPECL 100MHz – 156.25MHz ±20ppm ~ ±100ppm 2.5V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 5032XO C2 6-Pad 5.0 x 3.2 x 1.3 LVPECL 100MHz – 156.25MHz ±20ppm ~ ±100ppm 2.5V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 7050XO C4 6-Pad 7.0 x 5.0 x 1.6 LVPECL 100MHz – 156.25MHz ±20ppm ~ ±100ppm 2.5V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)


LVDS Output


Product Series Model Package Dimension
L x W x
H [mm]
Output Frequency Overall Frequency
Stability (ppm)
Supply
Voltage (V)
Operating Temperature Brief Sheet
[Automotive]
Brief Sheet
[Industrial]
Enquiry
 2520XO CM 6-Pad 2.5 x 2.0 x 1.0 LVDS 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 3225XO C8 6-Pad 3.2 x 2.5 x 0.95 LVDS 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 5032XO C2 6-Pad 5.0 x 3.2 x 1.3 LVDS 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 7050XO C4 6-Pad 7.0 x 5.0 x 1.6 LVDS 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)


HCSL Output


Product Series Model Package Dimension
L x W x
H [mm]
Output Frequency Overall Frequency
Stability (ppm)
Supply
Voltage (V)
Operating Temperature Brief Sheet
[Automotive]
Brief Sheet
[Industrial]
Enquiry
 2520XO CM 6-Pad 2.5 x 2.0 x 1.0 HCSL 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 3225XO C8 6-Pad 3.2 x 2.5 x 0.95 HCSL 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 5032XO C2 6-Pad 5.0 x 3.2 x 1.3 HCSL 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
 7050XO C4 6-Pad 7.0 x 5.0 x 1.6 HCSL 25MHz – 200MHz ±20ppm ~ ±100ppm 1.8V ~ 3.3V -20℃ – +70℃ (Standard)
-40℃ – +85℃ (Option)
-40℃ – +125℃ (Option)
